Vaults

Overview

Oldcastle Infrastructure’s electrical vaults, also referred to as splice boxes and switchgear vaults, are the industry’s leading product choice to protect and provide access to electrical cables and transformers, and are a preferred alternative to running electrical power cables above the ground and across utility poles. We offer a variety of different designs including one piece, three piece, and multi-piece configurations. With standard and customizable options, these vaults are the perfect example of value-added engineering with preinstalled equipment and accessories saving time and money on your next project. Available features include grade rings & risers, lifters, pulling irons, drainage sumps, term-a-ducts, knockouts, as well as racking to best fit your project needs.

Specs & Guides

Measurement System:

Your Project Deserves Expert Attention

Whether you're looking for additional product information or design assistance, or you’re ready to get a personalized quote, our dedicated team is here to guide you every step of the way.

	Name	Model	Height	Width	Length	Downloads
	233-LA Vault 2′ x 3′	233-LA	2’ 8”	2’	3’	View
PDF 020-233LA-10.pdf DWG 020-233LA-9-1.dwg
	444-LA Vault 3′-6″ x 3′-6″	444-LA	3’ 2”	3’ 6”	3’ 6”	View
PDF 020-444LA-10.pdf DWG 020-444LA-9-1.dwg
	504-LA Vault 4′-2″ x 4′-2″	504-LA	3’ 2”	4’ 2”	4’ 2”	View
PDF 020-504LA-9.pdf DWG 020-504LA-9-1.dwg
	644-LA Vault 3′-6″ x 5′-6″	644-LA	3’ 2”	3’ 6”	5’ 6”	View
PDF 020-644LA-9.pdf DWG 020-644LA-9-1.dwg
	676-LA/WA Vault 5′-6″ x 7′	676-LA/WA	6’	5’ 6”	7’	View
PDF 020-676-1LA-9.pdf DWG 020-676-1LA-9-1.dwg
	774-LA Vault 6′-4″ x 6′-4″	774-LA	3’ 1”	6’ 4”	6’ 4”	View
PDF 020-774LA-9.pdf DWG 020-774LA-9-1.dwg
	776-LA-5 Vault 6′-4″ x 6′-4″	776-LA-5	5’ 1”	6’ 4”	6’ 4”	View
PDF 020-776LA5-9.pdf DWG 020-776LA5-9-1.dwg
	4484-LA Vault 4′-4″ x 8′-4″	4484-LA	6’ 2”	4’ 4”	8’ 4”	View
PDF 020-4484LA-9.pdf DWG 020-4484LA-9-1.dwg
	4686-LA Vault 4′-6″ x 8′-6″	4686-LA	6’ 6”	4’ 6”	8’ 6”	View
PDF 020-4686LA-9.pdf DWG 020-4686LA-9-1.dwg
	5106-1-LA/WA Vault 5′ x 10′-6″	5106-1-LA/5106-1-WA	6’ 1”	5’	10’ 6”	View
PDF 020-51061LA-9.pdf DWG 020-51061LA-9-1.dwg
	687-2-LA/WA Vault 6′ x 8′	687-2-LA/687-2-WA	7’	6’	8’	View
PDF 020-687LA-9.pdf DWG 020-687LA-9-1.dwg
	612-3-LA Vault (3-pc.) 6′ x 12′	612-3-LA	6’ 8”	6’	12’	View
PDF 020-612LA3-9.pdf DWG 020-612LA3-9-1.dwg
	612-2-LA Vault (2-pc.) 6′ x 12′	612-2-LA	7’	6’	12’	View
PDF 020-612LA2-9.pdf DWG 020-612LA2-9-1.dwg
	712-LA Vault 7′ x 12′	712-LA	7’ 5”	7’	12’	View
PDF 020-712LA-9.pdf DWG 020-712LA-9-1.dwg
	810-LA Vault 8′ x 10′	810-LA	7’	8’	10’	View
PDF 020-810LA-9.pdf DWG 020-810LA-9-1.dwg
	816-LA Vault 8′ x 16′	816-LA		8’	16’	View
PDF 020-816LA-9.pdf DWG 020-816LA-9-1.dwg
	Sectional Vault Large – size varies	Sectional Vault				View
PDF 020-LG-SECTIONAL-9.pdf DWG 020-LG-SECTIONAL-9-1.dwg
	Rounded Corner Utility Vault	UV10X20RC		10’	20’	View
PDF NE_AVN_10x20xVaries_Utility-Vault-w-Rounded-Corners-Variable-Height_29212.pdf DWG NE_AVN_10x20xVaries_Utility-Vault-w-Rounded-Corners-Variable-Height_29212-1.dwg
	2’x2′ Utility Vault	MH2X2		2’	2’	View
PDF NE_AVN_2x2xVaries_Utility-Vault-Variable-Height_30032.pdf DWG NE_AVN_2x2xVaries_Utility-Vault-Variable-Height_30032-1.dwg
	3’x4′ Utility Vault	MH3X4		3’	4’	View
